Fairchild Q0265R Fsq0265R PWM Controller

Shop Q0265r Fsq0265r Q0265 Fsq0265rn Reemp Dm0265r Q0165r Dl0165r and more Circuitos Integrados at Latinafy.com

Introducing the Fairchild Q0265R PWM Controller – a high-performance integrated circuit designed for efficient power management. This controller features an integrated FET optimized for Valley Switching, ensuring low electromagnetic interference and high efficiency. With advanced protection functions including overload and thermal shutdown, it guarantees safe operation across various applications. Its compact DIP-8 package makes it easy to integrate into your electronic designs. Perfect for powering LCD monitors and TVs, this controller stands out for its versatile performance.

The Fairchild Q0265R is a cutting-edge PWM controller that incorporates an integrated FET, specifically designed for optimal performance and efficiency in power applications. One of its standout features is its optimization for Valley Switching (VSC), which minimizes electromagnetic interference through variable frequency control combined with inherent frequency modulation. This ensures not only a low EMI profile but also high efficiency by allowing minimum voltage switching, making it ideal for various electronic setups. In addition to outstanding performance, the Q0265R showcases a narrow frequency variation range over a wide load and input voltage variation. It boasts advanced burst-mode operation, enabling low standby power consumption. Safety and reliability are paramount with this controller, as it includes several protection mechanisms such as overload protection (OLP), over-voltage protection (OVP), and internal thermal shutdown (TSD). Other features like the internal startup circuit, under-voltage lockout (UVLO), and built-in soft-start add to its versatility, making it a valuable addition to your electronic toolkit. The Q0265R is encapsulated in a compact DIP-8 package, allowing for easy integration into various circuits. This PWM controller is particularly suitable for use in power supply applications for TVs and LCD monitors, promising efficiency and reliability. When you choose the Q0265R, you are opting for a product that combines high reliability with innovative technology, making it an exceptional choice for your electronic design needs.

Usage ideas This Fairchild PWM controller is perfect for powering LCD TVs and monitors, ensuring efficient operation. It can also be employed in various power supply applications where low electromagnetic interference is critical. Consider using it in consumer electronics where space and efficiency are paramount, as its compact DIP-8 package allows for easy integration into designs. Additionally, its advanced protective features make it well-suited for applications requiring high reliability and safety.

Frequently asked questions
What applications is the Q0265R suitable for?: The Q0265R is ideal for powering TVs and LCD monitors, as well as various other power supply applications.
What kind of protection does this controller offer?: It includes overload protection, over-voltage protection, and thermal shutdown among other safety features.
What is the package type of the Q0265R?: The Q0265R comes in a compact DIP-8 package.
How efficient is the Q0265R in power management?: It features optimized performance for Valley Switching, allowing for high efficiency and low EMI.
Is the Q0265R easy to integrate into designs?: Yes, its small size and built-in features make it an excellent choice for easy integration in various electronic applications.

- Brand: Fairchild
- Item Condition: New
- Model: FSQ0265RN / FSQ0265R / Q0265R
- SKU: FSQ0265R / Q0265R
- Manufacturer: Fairchild
- Sales Format: Unit
- Units per Pack: 1
- Product Type: Integrated Circuit
- Length: 9.5 mm
- Width: 6.5 mm
- Number of Pins: 8
- Device Part Number: FSQ0265RN
- Circuit Type: PWM

Vendor listing title: Q0265r Fsq0265r Q0265 Fsq0265rn Reemp Dm0265r Q0165r Dl0165r
