RB ZS-H2 Dual Channel H Bridge Module
30-Day Money-Back Guarantee
Not satisfied? Return within 30 days for a full refund.
All tariffs & duties are already pre-paid and pre-cleared. No additional payments will be required on delivery.
- Shipping Time:
- Ships within 2-5 business days after your purchase. We will receive your product at our warehouse and carefully package it for international shipping.
- SKU:
- MLB1620513103
- Condition:
- New
- Weight:
- 0.17 KGS
Description
Shop Módulo Ponte H 2 Canais Zs-h2 Reversão Motor 2.5a and more Placas de Microcontroladores at Latinafy.comThe RB ZS-H2 is a powerful dual channel H bridge module designed for seamless motor control. Operating within a voltage range of 2-10V and supporting a continuous current of 2.5A, it ensures robust performance for various applications. With its bidirectional peak current of 3A, this module can handle demanding tasks with ease. The PWM frequency range of 500Hz to 30kHz provides flexibility for optimal control signal management. Compact and efficient, the ZS-H2 is ideal for hobbyists and professionals alike seeking reliable motor control solutions.The RB ZS-H2 is an exceptional dual channel H bridge module that empowers you to control motors with precision and ease. With a compact size of 2.8x2.8cm, it is well-suited for a variety of projects requiring robust motor control. This module operates efficiently within a voltage range of 2 to 10V, making it versatile for different applications, while its continuous current capacity of 2.5A supports most standard motors. Additionally, it features bidirectional peak currents of up to 3A, ensuring reliable operation even in demanding situations.
One of the standout features of the ZS-H2 is its impressive PWM support, with a frequency range of 500Hz to 30kHz and a duty cycle ratio from 0 to 100%. This level of control allows you to fine-tune the performance characteristics of your motors, whether you're working on robotics, automation systems, or simply experimenting with new ideas. With a control signal voltage range of 1.8-5V and a low control current of just 2-5mA, integrating the ZS-H2 into your projects will be a straightforward endeavor. The module has excellent thermal and operational stability, functionally ranging from -20 to 85 degrees Celsius, allowing it to withstand a variety of environmental conditions.Usage ideas
This module is perfect for controlling small DC motors in robotics projects, home automation systems, or prototype development. It can be used in electric vehicles to manage motor direction and speed effectively. Hobbyists can utilize the ZS-H2 for model trains or remote-controlled vehicles where precise motor control is essential. Additionally, it's excellent for DIY projects involving automated systems that require reliable motor operation.Frequently asked questionsWhat is the input voltage range for the ZS-H2?: The ZS-H2 operates within a voltage range of 2 to 10V.What is the maximum current this module can handle?: This module supports a continuous current of 2.5A and a peak bidirectional current of 3A.Can I use this module for PWM control?: Yes, the ZS-H2 supports a PWM frequency range of 500Hz to 30kHz.What size is the ZS-H2 module?: The module has a compact size of 2.8x2.8cm.Is the ZS-H2 suitable for robotics applications?: Absolutely! The ZS-H2 is ideal for robotics projects that require precise motor control.- Brand: RB- Item Condition: New- Model: ZS-H2- SKU: RB0793- Length: 129 mm- Width: 129 mm- Height: 129 mm- Weight: 0.129 kg- Alphanumeric Model: ZS-H2- Operating Voltage: 2-10V- Microcontroller: ZS-H2- Recommended Minimum Input Voltage: 2V- Recommended Maximum Input Voltage: 10V- Input Voltage Minimum Limit: 2V- Input Voltage Maximum Limit: 10V- Flash Memory Capacity: 128 KB- Clock Frequency: 128 MHz- SRAM Capacity: 128 KB- EEPROM Capacity: 128 KB- Includes USB Cable: No- Input Voltage Limit: 5V- Recommended Input Voltage: 5V- Number of Analog Inputs: 2- Number of Digital I/O Pins: 2Vendor listing title: Módulo Ponte H 2 Canais Zs-h2 Reversão Motor 2.5a
